| Key Features | : | 1'' CMOS Sensor 4K@60fps Mechanical Shutter 5 Directions of Obstacle Sensing Dual Band 7 km video transmission 30-Minute Flight Time |
DJI Phantom & Accessories
PHANTOM 4 Pro
An uprated camera is equipped with a 1-inch 20-megapixel sensor capable of shooting 4K/60fps video and Burst Mode stills at 14 fps. The adoption of titanium alloy and magnesium alloy construction increases the rigidity of the airframe and reduces weight, making the Phantom 4 Pro similar in weight to the Phantom 4. The FlightAutonomy system adds dual rear vision sensors and infrared
sensing systems for a total of 5-direction of obstacle sensing and 4-direction of obstacle avoidance.
AVAILABILITY: In stock
KEY FEATURES
HIGHLIGHTS
| Dimensions | : | 289.5 × 289.5 × 196 mm (L×W×H) |
| Weight | : | 1375 g |
| Flight Performance | : | Max Flight Time: 30 minutes Max Speed: 72 kph (S - mode) 50 kph (P - mode) |
| Intelligent Flight Modes | : | ActiveTrack, Tapfly Tripod Mode Draw,Gesture Mode Point of Interest Course Lock Home Lock Follow me Waypoints |
| Photography | : | 3-Axis Mechanical Gimbal 1'' CMOS Mechanical Shutter Max Video Resolution: 4K @60 fps 4k @60 fps Max Image Size: 20 MP |
| Obstacle Sensing | : | Forward and backward obstacle sensing: 0.7 - 15m TOF on both sides: 0.2 - 7 m |
| Control Modes | : | Remote Controller |
| Max Transmission Distance (Unobstructed, Free Of Interference) | : | Remote Controller: 2.400 - 2.483 GHz FCC: 7000 m CE: 4000 m SRRC: 4000 m 5.725 - 5.825 GHz FCC: 7000 m CE: 2000 m SRRC: 5000 m |
AIRCRAFT
| Takeoff Weight | : | 1375 g |
| Diagonals | : | 289.5×289.5×196 mm (L×W×H) |
| Diagonal Distance | : | 350 mm |
| Max Descent Speed | : | 4 m/s (S - mode) 3 m/s (P - mode) |
| Max Ascent Speed | : | 6 m/s (S - mode) 5 m/s (P - mode) |
| Max Speed (Near Sea Level, No Wind) | : | 72 kph (S - mode) 50 kph (P - mode) |
| Max Service Ceiling Above Sea Level | : | 6000 m |
| Max Flight Time | : | 30 minutes (at a consistent 20 kph) |
| Max Flight Distance (No Wind) | : | 14 km |
| Max Wind Speed Resistance | : | 29 - 38 kph |
| Max Tilt Angle | : | 42° (S - mode) 25° (P - mode) |
| Max Angular Velocity | : | 250°/s (S - mode) 150°/s (P - mode) |
| Operating Temperature Range | : | 0°C - 40°C |
| Operating Frequency | : | 2.400 - 2.483 GHz 5.725 - 5.825 GHz |
| Transmission Power (EIRP) | : | 2.400 - 2.483 GHz FCC: ≤26dBm CE: ≤20dBm SRRC: ≤20dBm 5.725 - 5.825 GHz FCC: ≤26 dBm CE: ≤14 dBm SRRC: ≤26 dBm |
| GNSS | : | GPS+GLONASS |
| Hovering Accuracy Range | : | Vertical: ±0.1 m (with Vision Positioning) ±0.5 m (with GPS Positioning) Horizontal: ±0.3 m (with Vision Positioning) ±1.5 m (with GPS Positioning) |
SENSING SYSTEM
| Forward | : | Precision Measurement Range: 0.7 - 15 m Detectable Range: 0.7 - 30 m Effective Sensing Speed: ≤14 m/s Field of View (FOV) : Horizontal 60°, Vertical ±27° |
| Backward | : | Precision Measurement Range: 0.7 - 15 m Detectable Range: 0.7 to 30 m Effective Sensing Speed: ≤14 m/s Field of View (FOV) : Horizontal 60°, Vertical ±27° |
| Side | : | Obstacle Sensing Range: 0.2 - 7 m Detectable Range: 0.7 - 30 m Effective Sensing Speed: ≤2 m/s Field of View (FOV) : Horizontal 70°, Vertical ±10° |
| Downward | : | Altitude Range: 0 - 10 m Operating Range: 0 - 10 m |
| Operating Environment | : | Forward and Backward: Surface with clear pattern and adequate lighting (lux>15) Side: Detects diffuse reflective surfaces (>8%) larger than 20×20 cm (walls, trees, people, etc.) Downward: Surface with clear pattern and adequate lighting (lux>15) Speed ≤14m/s (at 2 m, sufficient brightness) |
REMOTE CONTROLLER
| Operating Frequency | : | 2.400 - 2.483 GHz 5.725 - 5.825 GHz |
| Max Transmission Distance (Unobstructed, Free Of Interference) | : | 2.400 - 2.483 GHz FCC: 7000 m CE: 4000 m SRRC: 4000 m 5.725 - 5.825 GHz FCC: 7000 m CE: 2000 m SRRC: 5000 m |
| Operating Temperature Range | : | 0℃ - 40℃ |
| Transmission Power (EIRP) | : | 2.400 - 2.483 GHz FCC: ≤26 dBm CE: ≤20 dBm SRRC: ≤20 dBm 5.725 - 5.825 GHz FCC: ≤26 dBm CE: ≤14 dBm SRRC: ≤20 dBm |
| Battery | : | 6000 mAh |
| Operating Current/Voltage | : | 1.2 A ⎓ 7.4 V |
| Supported Mobile Device Size | : | Max Length: 170 mm Max Thickness: 13 mm |
INTELLIGENT FLIGHT BATTERY
| Capacity | : | 5870 mAh |
| Voltage | : | 15.2 V |
| Max Charging Voltage | : | 17.4 V |
| Battery Type | : | LiPo 4S |
| Energy | : | 89.2 Wh |
| Net Weight | : | 468 g |
| Charging Temperature Range | : | 5℃ - 40℃ |
| Max Charging Power | : | 100 W |
GIMBAL
| Mechanical Range | : | Tilt: -90 to +30° Pan: -30 to +30° |
| Controllable Range | : | Pitch: -90° to +30° |
| Stabilization | : | 3 - axis (tilt, roll, pan) |
| Max Control Speed (Tilt) | : | 120° /s |
| Angular Vibration Range | : | ±0.02° |
CAMERA
| Sensor | : | 1'' CMOS Effective Pixels: 20 MP |
| Lens | : | FOV: 84 ° 35 mm Format Equivalent: 24 mm Aperture: f/2.8-11 Shooting Range: 1 m to ∞ (auto focus) |
| ISO Range | : | Video: 100 - 3200(auto) 100 - 6400(manual) Photo: 100 - 3200(auto) 100 - 12800(manual) |
| Shutter Speed | : | Electronic Shutter: 8 - 1/8000 s Mechanical Shutter: 8 - 1/2000 s |
| Still Image Size | : | 3:2: 5472×3648 4:3: 4864×3648 16:9: 5472×3078 |
| Still Image Size While Recording Video | : | 4096×2160 (24/25/30/48/50 p) 3840×2160 (24/25/30/48/50/60 p) 2720×1530 (24/25/30/48/50/60 p) 1920×1080 (24/25/30/48/50/60/120 p) |
| Still Photography Modes | : | Single Shot Burst Shooting: 3/5/7/10/14 frames Auto Exposure Bracketing(AEB): 3/5 bracketed frames at 0.7 EV bias Interval: 2/3/5/7/10/15/20/30/60 s |
| Video Resolution | : | H.265 C4K: 4096×2160 24/25/30 p @100 Mbps 4K: 3840×2160 24/25/30 p @100 Mbps 2.7K: 2720×1530 24/25/30 p @65 Mbps 2.7K: 2720×1530 48/50/60 p @80 Mbps FHD: 1920×1080 24/25/30 p @50 Mbps FHD: 1920×1080 48/50/60 p @65 Mbps FHD: 1920×1080 120 p @100 Mbps HD: 1280×720 24/25/30 p @25 Mbps HD: 1280×720 48/50/60 p @35 Mbps HD: 1280×720 120 p @60 Mbps H.264 C4K: 4096×2160 24/25/30/48/50/60 p @100 Mbps 4K: 3840×2160 24/25/30/48/50/60 p @100 Mbps 2.7K: 2720×1530 24/25/30 p @80 Mbps 2.7K: 2720×1530 48/50/60 p @100 Mbps FHD: 1920×1080 24/25/30 p @60 Mbps FHD: 1920×1080 48/50/60 p @80 Mbps FHD: 1920×1080 120 p @100 Mbps HD: 1280×720 24/25/30 p @30 Mbps HD: 1280×720 48/50/60 p @45 Mbps HD: 1280×720 120 p @80 Mbps |
| Supported File Systems | : | FAT32（≤ 32 GB ） exFAT（> 32 GB） |
| Photo | : | JPEG, DNG (RAW) |
| Max Video Bitrate | : | 100 Mbps |
| Video Format | : | MP4/MOV (H.264/AVC; H.265/HEVC） |
CHARGER
| Input | : | 100 - 240 V, 50/60 Hz, 1.4 A |
| Output | : | 17.5 V ⎓ 0~5.7 A |
| Voltage | : | 17.5 V |
| Rated Power | : | 100 W |
APP / LIVE VIEW
| Video Transmission System | : | OcuSync |
| Name | : | DJI GO 4 |
| Live View Quality | : | Remote Controller: 720 p/1080 p @30 fps Mobile Device: 720 p/1080 p @30 fps DJI Goggles: 720 p @30 fps/720 p @60 fps/1080 p @30 fps |
| Latency (Depending On Environmental Conditions And Mobile Device) | : | 160 ms -170 ms |
| Required Operating Systems | : | iOS v9.0 or later Android v4.4.0 or later |
