DJI MAVIC Pro

MAVIC Pro

MAVIC Pro

The DJI Mavic Pro is a small yet powerful drone that turns the sky into your creative canvas easily and without worry, helping you make every moment an aerial moment. Its compact size hides a high degree of complexity that makes it one of DJI’s most sophisticated flying cameras ever. 24 high-performance computing cores, an all-new transmission system with a 4.3mi (7km) *range, 5 vision sensors, and a 4K camera stabilized by a 3-axis mechanical gimbal, are at your command with just a push of your thumb or a tap of your finger. *Unobstructed, free of interference, when FCC compliant.

AVAILABILITY: In stock

AIRCRAFT
VISION SYSTEMM
REMOTE CONTROLLER
BATTERY
CAMERA
GIMBAL
CHARGER
APP/LIVE View

AIRCRAFT

Folded	:	H83mm x W83mm x L198mm
Diagonal Size (Propellers Excluded)	:	1.62 lbs (734 g) (exclude gimbal cover) 1.64 lbs (743 g) (include gimbal cover)
Max Ascent Speed	:	16.4 ft/s (5 m/s) in Sport mode
Max Descent Speed	:	9.8 ft/s (3 m/s)
Max Speed	:	40 mph (65 kph) in Sport mode without wind
Max Service Ceiling Above Sea Level	:	16404 feet (5000 m)
Max Flight Time	:	27 minutes (no wind at a consistent 15.5 mph (25 kph))
Max Hovering Time	:	24 minutes (no wind)
Overall Flight Time	:	21 minutes ( In normal flight, 15% remaining battery level )
Max Total Travel Distance (One Full Battery, No Wind)	:	8 mi (13 km, no wind)
Operating Temperature Range	:	32° to 104° F (0° to 40° C)
Satellite Positioning Systems	:	GPS / GLONASS
Hover Accuracy Range	:	Vertical: +/- 0.1 m (when Vision Positioning is active) or +/-0.5 m Horizontal: +/- 0.3 m (when Vision Positioning is active) or +/-1.5 m
Operating Frequency	:	FCC: 2.4-2.4835GHz; 5.150-5.250 GHz; 5.725-5.850 GHz CE: 2.4-2.4835GHz; 5.725-5.850 GHz SRRC： 2.4-2.4835 GHz;5.725-5.850 GHz
Transmission Power (EIRP)	:	2.4GHz FCC:<=26 dBm; CE: <=20 dBm; SRRC:<=20 dBm; MIC:<=18 dBm 5.2 GHz FCC:<=23 dBm 5.8 GHz FCC:<=23 dBm; CE <=13 dBm; SRRC: <=23 dBm; MIC: -

Vision System

Vision System	:	Forward Vision System Downward Vision System
Obstacle Sensory Range	:	Precision measurement range: 2 ft (0.7 m) to 49 ft (15 m) Detectable range: 49 ft (15 m) to 98 ft (30 m)
Operating Environment	:	Surface with clear pattern and adequate lighting (lux > 15)
Velocity Range	:	≤22.4 mph (36 kph) at 6.6 ft (2 m) above ground
Altitude Range	:	1 - 43 feet (0.3 - 13 m)
Operating Range	:	1 - 43 feet (0.3 - 13 m)

REMOTE CONTROLLER

Operating Frequency	:	2.4 GHz to 2.483 GHz
Max Transmission Distance	:	FCC Compliant: 4.3 mi (7 km); CE Compliant: 2.5 mi (4 km) SRRC Compliant: 2.5mi (4 km) MIC Compliant: 2.5 mi (4 km) (Unobstructed, free of interference)
Operating Temperature Range	:	32° to 104° F ( 0° to 40° C )
Battery	:	2970mAh
Transmitter Power (EIRP)	:	FCC：<=26 dBm CE：<=20 dBm SRRC: <=20 dBm MIC: <=18 dBm
Operating Current/Voltage	:	950mA @ 3.7V
Supported Mobile Device Size	:	Thickness Supported:6.5-8.5mm Max length: 160mm Supported USB port types: Lightning, Micro USB(Type-B),USB(Type-C)™

INTELLIGENT FLIGHT BATTERY

Capacity	:	3850 mAh
Voltage	:	15.4 V
Max Charging Voltage	:	17.6 V
Battery Type	:	LiPo 4S
Energy	:	59.29 Wh
Net Weight	:	297 g
Charging Temperature Range	:	5℃ - 40℃
Operating Temperature Range	:	-10℃ to 40℃
Max Charging Power	:	80 W

GIMBAL

Controllable Range	:	Pitch: -90° to +30°
Stabilization	:	3-axis (pitch, roll, yaw)

CAMERA

Sensor	:	1/2.3” (CMOS), Effective pixels:12.35 M (Total pixels:12.71M)
Lens	:	FOV 78.8° 26 mm (35 mm format equivalent) f/2.2 Distortion < 1.5% Focus from 0.5 m to ∞
ISO Range	:	video: 100-3200 photo: 100-1600
Electronic Shutter Speed	:	8s -1/8000 s
Image Size	:	4000×3000
Still Photography Modes	:	Single shot Burst shooting: 3/5/7 frames Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias c Interval
Video Recording Modes	:	C4K: 4096×2160 24p 4K: 3840×2160 24/25/30p 2.7K: 2720x1530 24/25/30p FHD: 1920×1080 24/25/30/48/50/60/96p HD: 1280×720 24/25/30/48/50/60/120p
Max Video Bitrate	:	60 Mbps
Supported File System	:	FAT32 ( ≤ 32 GB ); exFAT ( > 32 GB ))
Photo Format	:	JPEG, DNG
Video Format	:	MP4, MOV (MPEG-4 AVC/H.264)
Supported SD Cards	:	Micro SD™ Max capacity: 128 GB. Class 10 or UHS-1 rating required
Operating Temperature Range	:	32° to 104° F ( 0° to 40° C )

CHARGER

Voltage	:	100-240V， 50-60Hz， 1.8A
Rated Power	:	50W

APP / LIVE VIEW

Mobile App	:	DJI GO 4
Live View Quality	:	720p@30fps, 1080p@30fps（Remote Controller） 720p@30fps(Wi-Fi) 720p@60fps, 1080p@30fps（DJI Goggles）
Latency	:	160-170ms (depending on conditions and mobile device)
Required Operating Systems	:	iOS 9.0 or later Android 4.1.2 or later
